Counter Fire Door

SDI counter fire doors are a clean and attractive solution for adding security to your facility. All SDI counter fire doors use a compact 10” bracket on all door sizes. Ideal for minimal headroom space applications. Drop test is simple and can be performed by a single technician. Resets from one side of opening, reducing testing costs. Mounting available in the following wall types: Solid concrete, Concrete block, structural steel studs with 2 layers of fire rated gypsum board, wood studs with 2 layers of fire rated gypsum board, fire rated gypsum board.

Door Features

  • Rugged 2” flat slats 22 ga. steel
  • Corrosion resistant grey prime finish or galvanized steel finish
  • Oil tempered torsion springs with high cycle life
  • Compact mechanical governor controls automatic closing speed of 6" to 2' per second
  • Fuse link release device available


Slats 2" flat slats, 22ga steel
Fire Label 3/4, 11/2, 3 hours- (4 hours available for masonry applications)
Maximum opening width 13'
Maximum opening height 9'
Maximum sq footage of curtain 96' ft2
Maximum size for drywall with wood jambs 8'0" x 9'0"

Specifications


Click on Model name to download specifications

Model
Operation
Finish
Mounting
Download
BPCF
Push Up
Grey Prime
Between Jamb
BPCF
Push Up
Galvanized
Between Jamb
FPCF
Push Up
Grey Prime
Face of Wall
FPCF
Push Up
Galvanized
Face of Wall

Slat Options


2" Flat slats available in 22 ga. steel

slat profile options slat colour options

Operation


  • Each available in between jamb or face of wall mounting
  • Push-up
  • Crank

Hardware Options


Slide Bolt Lock

Safety Options:
Nema 7/9 Explosion Proof Motor
Nema 4 Water Proof Motor
Nema 4X Corrosion Proof Motor
Fire Link Release device
Sensing edge
