High-Performance Springless
Sectional Doors
High-speed springless doors by Service Door Industries are an attractive solution where unobstructed visibility is required. These high-cycle doors are designed to withstand the rigours of busy service centers. The SDI reputation for quality sectional door products is clearly reflected in our aluminum products' distinctive appearance and performance. These doors offer many years of trouble-free service and energy savings.
System Features
- High speed and low maintenence costs with energy efficiency to maximize your return on investment
- All components are proven through many years of trouble free high cycle applications
- The springless design requires no center mounting supports and eliminates the cost of spring replacement
- Standard Maintenence items such as limit and door level adjustments are made from the floor level, without the use of a lift
- Local manufacturing and inventory ensure parts and service availability to minimize costs
- A wide range of door face options can match the exterior of any project
- Emergency chain hoist built in
- UL325 approved panel & reflective photocell
- Wireless air wave safety edge included
| Power Required | 230v 1ph 60 hz | |
| Transformers Available | 115v / 208v / 460v / 575v | |
| Max Door Height | 18' | |
| Model | Door Weight | Speed |
| SDS-400-24 | 400lbs | 24" per second |
| SDS-575-15 | 575lbs | 15" per second |
Operation
Safedrive Operator & Panel
Standard Package
- Safedrive Operator
- Control Panel (UL325 Approved)
- Photoreflective photoeye (UL325 Approved)
- High Cycle Rollers
- Barrel
Car Wash Package
- Stainless Steel Control Panel
- Thru-beam car wash photcell
- Drive with covered brake
- Powdercoated track & hardware
- Powdercoated barrel
Safety Options
Monitored Light Curtain (36" or 72")
Motion Detector
